12-Alfenol / UNS K91200 (Modified) / 1.3980 (Modified) / FeAl12

12Alfenol / Hypermal / Yu12 – High-Quality Aluminum-Iron Alloy

General Characteristics

12Alfenol (also known as Hypermal or Yu12) is a specialized iron-based alloy with aluminum addition, featuring unique combination of magnetic and mechanical properties. Developed for high-frequency electromagnetic devices.

Chemical Composition

Main components:

• Iron (Fe): 86-88%

• Aluminum (Al): 11-13%

• Other elements: <1% (Mn, Si, C)

Magnetic Properties

• Initial permeability (μi): 3,500-5,000

• Maximum permeability (μmax): 35,000-50,000

• Coercive force (Hc): 4-8 A/m

• Saturation induction (Bs): 0.75-0.85 T

• Resistivity: 145 μΩ·cm

Mechanical Properties

• Tensile strength: 450-550 MPa

• Brinell hardness (HB): 130-160

• Density: 6.7 g/cm³

• Melting point: ≈1500°C

Main Applications

1. High-frequency devices:

   • HF transformer cores

   • Inductors and coils

   • Switching power supplies

2. Acoustic systems:

   • Loudspeaker magnetic circuits

   • Pickup devices

3. Special applications:

   • Position sensors

   • Electromagnetic shields

   • Magnetostriction devices

Key Advantages of 12Alfenol

✔ High magnetic permeability in HF range
✔ Low eddy current losses
✔ Excellent corrosion resistance
✔ Good mechanical properties
✔ Stable parameters when heated

Comparative Characteristics

Delivery Forms 12Alfenal
