DC05ED Sheet Steel — Specifications, Applications, Properties General Technical Characteristics DC05ED is a premium low-carbon cold-rolled steel grade developed for deep and extra-deep drawing processes, with the ability to be directly enamelled. The ED (Enamelled Drawing) designation indicates its compatibility with enamel coatings. It complies with EN 10209, the European standard for cold rolled low […]
DC05ED is a premium low-carbon cold-rolled steel grade developed for deep and extra-deep drawing processes, with the ability to be directly enamelled. The ED (Enamelled Drawing) designation indicates its compatibility with enamel coatings. It complies with EN 10209, the European standard for cold rolled low carbon steel flat products intended for enameling.
Supplied in sheets or coils with thicknesses from 0.5 mm to 2 mm, DC05ED offers exceptional formability, high surface quality, and consistent dimensional stability. It is ideal for applications requiring flawless surfaces and minimal internal stress.
Due to its outstanding plasticity and structural purity, DC05ED sheet steel is widely used in industries where high deformation and smooth surface finishing are critical. Main applications include:
Looking to buy DC05ED steel? We offer certified material, custom cutting, and fast delivery — direct from stock.
The high-quality metal structure ensures low rejection rates during enameling and forming processes.
| Element | Max. Content (%) |
|---|---|
| Carbon (C) | 0.05 |
| Manganese (Mn) | 0.40 |
| Silicon (Si) | 0.03 |
| Sulfur (S) | 0.02 |
| Phosphorus (P) | 0.020 |
| Aluminum (Al) | ≥0.020 (residual) |
This optimized composition ensures softness, clean surfaces, and excellent thermal behavior during enameling.
| Property | Value |
|---|---|
| Yield Strength (Rp0.2), MPa | ≤ 150 |
| Tensile Strength (Rm), MPa | 270–340 |
| Elongation, % | ≥ 40 |
| Brinell Hardness | ≤ 65 HB |
These properties make DC05ED steel perfect for high-precision parts where complex shaping and perfect coating are required.
DC05ED cold rolled sheet steel is the ideal choice for deep-drawing and enameling applications. We offer competitive prices, certified quality, and fast delivery. Custom sheet sizes and packaging options are available.
📦 Contact us today or place your order online — we guarantee reliable service and product consistency.
| Steel grades | DC01EK – DC05EK (EN 10209, EN 10131) |
| Surface quality: | A – Normal B – improved (smoothed) |
| Surface protection: | O – lubricated NOL – no lubrication |
| Steel sheet thickness: | 0 .4 – 3.0 mm |
| Width range: | 10.1 – 1550 mm |
