Steel 1.4501 / 02Х25Н7М4 4501 super duplex steel is an anti-corrosion stainless steel, the price of which in our company is one of the most affordable on the market. This product has excellent performance characteristics and a wide range of applications. Features Buying stainless steel is necessary for the needs of almost any industry. Steel […]
4501 super duplex steel is an anti-corrosion stainless steel, the price of which in our company is one of the most affordable on the market. This product has excellent performance characteristics and a wide range of applications.
Features
Buying stainless steel is necessary for the needs of almost any industry. Steel is distinguished by excellent strength, good ductility at low temperatures. This material is an analogue and a good inexpensive alternative to very expensive nickel- and titanium-containing alloys of the fifth class.
Despite the fact that the alloy can be welded in any way, experts do not recommend using gas welding. This type of alloy often has weld defects when using this method.
Applications
4501 duplex stainless steel is mainly used in corrosive environments. The strongest acids and alkalis do not affect the alloy, which predetermined the use of steel in industry, as well as in the medical industry.
As noted above, the main consumers of the alloy are industries such as:
• Chemical production and transportation;
• Oil and gas industry;
• Food and medical industry.
Resistance to high pressure allowed the steel grade to be used in the production of tanks and pipelines, storage and transportation products under high pressure.
Chemical composition in steel 1.4501
|
C |
Si |
Mn |
P |
S |
Cr |
Ni |
Mo |
Cu |
W |
N |
Fe |
|
<0.03 |
<1,0 |
<1,0 |
<0.035 |
<0.015 |
24.0-26.0 |
6.0-8.0 |
3.0-4.0 |
0.5-1.0 |
0.5-1.0 |
0.2-0.3 |
Other |
Mechanical properties of material 1.4501
| Yield strength, min., ReH, MPa |
550 |
|
| Tensile strength (tensile strength), min., Rm, MPa |
800-1000 |
|
| Relative elongation, min., % |
20 |
|
| Impact work KV at 20°C, min., J |
100 |
|
|
Impact work KV at -196°C -320°F , min., J |
Cross Patterns |
40 |
| Wheel EN 1.4501 | Diameter: 6 – 500mm |
| Sheet EN 1.4501 | Thickness: 0.5 – 100mm
td> |
| Pipe EN 1.4501 | – Hot rolled round pipe diameter from 38 to 244.5 mm, thickness from 3 to 25 mm
-Cold-drawn round pipe diameter from 6 to 219.1mm thickness from 0.9 to 14.2mm |
| Hex EN 1.4501 | Diameter p: 17-65mm |
| Strip EN 1.4501 | Thickness: 5-50mm; Width: 50-250mm |
